How do you get more USB Headers? How Do You Get More USB Headers? Method 1: DIY USB 2.0 Header Duplicationįor USB 2.0 Headers specifically, it turns out you can very easily turn a single header on your motherboard into a port for 2 cables. So, these are the basic USB Headers you can expect to see on your motherboard.īut maybe your case has Type-C support, and your motherboard doesn’t, or you have more USB ports but nowhere to plug in the Header cable. They are mostly located on the right side of your Motherboard, right next to the ATX Power Connector: This is also called a USB Type-E Header, pictured below. USB 3.2 Gen 2 Headers don’t have visible pins but are more similar to USB Type-A in appearance. While USB 3.2 Gen 1 (USB 3.0) Headers are often either placed at the bottom as well or at the right side of your Motherboard:
USB 2.0 Headers are usually located at the bottom side of your Motherboard: USB 2.0 and USB 3.2 Gen 1 (USB 3.0) Headers look the most similar of the three, having a similar pin-based design.
USB 3.2 Gen 1 Headers (Formerly also known as USB 3.0).However they may be labeled, though, there are three basic types of internal USB headers: The “F” stands for “Front” and refers to your PC Case’s front access panel, while a “J” may indicate “Jumper,” which refers to the pins on your motherboard that can be shorted to close a circuit (like jump-starting a car). Your motherboard’s USB Headers will look something like the below, and the headers may be labeled as “FPANEL USB”, “F_USB”, “USB30”, “JUSB1” or similar. Internal USB Headers on your Motherboard don’t have the same connectors as your external USB Connectors. USB headers refer to dedicated USB connectors on your motherboard that are used for USB ports on your PC case, usually front panel USB ports.Įssentially, they are the end-point for connecting your external (Chassis) USB ports to the motherboard inside your PC through an extension cable. No need to waste time: let’s dive right in! What are USB Headers? If so, this is the article for you, especially if you’re seeing the term for the first time and want a quick idea of what USB headers are, how to identify them, and even how to get more of them when needed.
